Electrolux T4900 - Sliding Door Drum Replacement

Drum with bearing
Service
manual
82
Sliding Door
Replacing drum
Whenremoving/replacingthedrum
inadryerwithSlidingDoor,allextra
equipmentforSlidingDoormustbe
dismounted.
1.Sidescreensinthefiltercompartment.
2.Leftorrightpanelwithmicroswitch.
3.Wire
4.Crossbar
5.Heatingunitdoor
6.2uppersidepanels
7.Railinwhichthedoorslides
8.Loadingdoors
9.Supportrail
Afterthis,theprocedurefordismounting
thedrumisexactlythesameasona
dryerwithstandarddoor,asdescribed
earlier.
