Electrolux T4900 - Page 83

83
Drum with bearing
Service
manual
Removing Sliding Door equipment:
Recommended for removing the
drum.
1. Disconnectthepowertothedryer.
2.Fig.1RemovesidescreensPinfilter
compartment.
Onthesidepanelwiththedoorswitch,
removerivetsusingachiseloradrill.
Donotremovethetopandbottom
rivets.Thismeansthatthepanelis
onlysecuredatthetopandthebottom.
3.Fig.2Removethewire:Adjustaboard
to555mmforsecuringdoors.
 SeesectionSliding Door
1
P
2
555 mm
