G4500 BLACKBOX Unit
G3500 BLACKBOX Unit
QUANTITY
ILLUSTRATION
DESCRIPTION & PART NUMBER
As Ordered
300 A Flexible Current Clamp
SOA-9091-3000
Measurement Range 9A ÷ 1050A
Output Signal AC: 46mV/1KA
Operating Temperature -20ºC to + 60ºC
Cable Length 2m
As Ordered
3000 A Flexible Current Clamp
SOA-9045-3001
Measurement Range 10Hz ÷ 20kHz
Output Signal AC: 46mV/1KA
Operating Temperature -20ºC to + 60ºC
Cable Length 2m
As Ordered
Adaptor - Elspec Clamps to BNC (160cm)
SOA-0270-0000
As Ordered
Adaptor - Elspec Clamps to Fixed Banana (60cm)
SOA-0270-0001
As Ordered
Adaptor Elspec Clamps to Separated Banana (160cm)
SOA-0270-0002
As Ordered
Extension Cable for Elspec Clamps (600cm)
SOA-4500-0000
