table - waveform options:
The table outlines the sections' Parameter options (for your selection) including their Definition:
Cycle Selection (1-4 Cycles)
Checking the "All graphs" box will automatically select all the boxes below
Depending on your power configuration, you can view all combinations of
phase to phase and phase to line voltage and current combinations by making
selections in the appropriate check boxes
chart options:
By right-clicking on the chart you have various chart options & capabilities available to you:
