Figure A-8. Rosemount 5402 with Parabolic Antenna (Model Code: 8A)
Purging connection, inlet BSPG 3/8"
s60
3.5 (88) 3.6 (92)
5.2 (133)
7.3 (185)
10.8 (273)
3.2 (82.4)
Ø 7.4 (188)
9.3 (237)
3.4 (87)
BSPG 3.5"
9.3 (237)
3.4 (87)
Ø 3.9 (99)
Threaded connection
Welded connection
±15°
Process connection availability
●
Available as standard
❍
Available as special, consult factory
N/A Not available
Antenna code
Process connection
8A
8 in./DN 200 PN 6/200A 5K
●
10 in. /DN 250 PN 6/250A 5K
●
3.5-in. threaded connection
●
3.5-in. welded connection
●
Bracket mounting N/A
7.1 (180)
All dimensions are in inches (mm).
