Specifications and Reference Data
229
Specifications and Reference Data
October 2018
Reference Manual
00809-0100-4026, Rev KC
Parabolic antennas
8A
(6)(7)
Parabolic antenna, 8 in. (DN200), 316L SST (EN1.4404) with swiveling connection
★
Other antennas
XX Customer specific
Tank sealing, O-ring material
PV Viton Fluoroelastomer
★
PK Kalrez 6375 Perfluoroelastomer
★
PE Ethylene Propylene (EPDM)
★
PB Nitrile Butadiene (NBR)
★
PF Fluorosilicone (FVMQ) for parabolic antenna
★
NA
(8)
None
★
Process connection and material (for antenna availability,
see “Dimensional drawings and mechanical properties” on page 219)
ASME flanges (316/316L SST)
(9)
AA 2 in. Class150
★
AB 2 in. Class300
★
BA 3 in. Class 150
★
BB 3 in. Class 300
★
CA 4 in. Class 150
★
CB 4 in. Class300
★
DA 6 in. Class150
★
EA 8 in. Class150
★
FA 10 in. Class150
★
EN flanges (EN 1.4404 SST)
(9)
HB DN 50 PN 40
★
IB DN 80 PN 40
★
JA DN 100 PN 16
★
JB DN 100 PN 40
★
KA DN 150 PN 16
★
LA DN 200 PN 16
★
LF DN 200 PN 6
★
MF DN 250 PN 6
★
Table A-8. Rosemount 5402 Ordering Information
The starred options (
★
) represents the most common options and should be selected for best delivery.
The non-starred offerings are subject to additional delivery lead time.
