244 Unidrive SPM User Guide
www.controltechniques.com Issue Number: 3
Applications module parameters
*See trip SLX.Er, Automation (Applications) module category
on page 285
.
Parameter
Range(
Ú) Default(Ö)
Type
x.01 Solutions Module ID 0 to 599 RO Uni PT US
x.02 Solutions Module software version 0.00 to 99.99 RO Uni NC PT
x.03 DPL program status None (0), Stop (1), Run (2), Trip (3) RO Txt NC PT
x.04 Available system resource 0 to 100 RO Uni NC PT
x.05 RS485 address 0 to 255 11 RW Uni US
x.06 RS485 mode 0 to 255 1 RW Uni US
x.07 RS485 baud rate
300 (0), 600 (1), 1200 (2), 2400 (3), 4800 (4),
9600 (5), 19200 (6), 38400 (7), 57600 (8),
115200 (9) baud
4800 (4) RW Txt US
x.08 RS485 Turnaround delay 0 to 255 ms 2 RW Uni US
x.09 RS485 Tx enable delay 0 to 1 ms 0 RW Uni US
x.10 DPL Print Routing SYPT: OFF (0), RS485: On (1) SYPT: OFF (0) RW Bit US
x.11 Clock task scheduling (ms) 0 to 200 10 RW Uni US
x.12 POS task scheduling rate
dISAbLEd (0), 0.25 ms (1), 0.5 ms (2), 1 ms (3),
2 ms (4), 4 ms (5), 8 ms (6)
dISAbLEd (0) RW Txt US
x.13 Enable autorun OFF (0) or On (1) On (1) RW Bit US
x.14 Global run time trip enable OFF (0) or On (1) OFF (0) RW Bit US
x.15 Disable reset on trip cleared OFF (0) or On (1) OFF (0) RW Bit US
x.16 Encoder data update rate 0 to 3 0 RW Uni US
x.17 Enable parameter over range trips OFF (0) or On (1) OFF (0) RW Bit US
x.18 Watchdog enable OFF (0) or On (1) OFF (0) RW Bit US
x.19 Save request OFF (0) or On (1) OFF (0) RW Bit NC
x.20 Enable power down save OFF (0) or On (1) OFF (0) RW Bit US
x.21
Enable menu 20 save and
restore
OFF (0) or On (1) OFF (0) RW Bit US
x.22 CTNet Token Ring ID 0 to 255 0 RW Uni US
x.23 CTNet node address 0 to 255 0 RW Uni US
x.24 CTNet baud rate 5.000 (0), 2.500 (1), 1.250 (2), 0.625 (3) 2.500 (1) RW Txt US
x.25 CTNet sync setup 0,000 to 9,999 0,000 RW Uni US
x.26
CTNet easy mode - first cyclic
parameter destination node
0 to 25,503 0 RW Uni US
x.27
CTNet easy mode - first cyclic source
parameter
0 to 9,999 0 RW Uni US
x.28
CTNet easy mode - second cyclic
parameter destination node
0 to 25,503 0 RW Uni US
x.29
CTNet easy mode - second cyclic
source parameter
0 to 9,999 0 RW Uni US
x.30
CTNet easy mode - third cyclic
parameter destination node
0 to 25,503 0 RW Uni US
x.31
CTNet easy mode - third cyclic source
parameter
0 to 9,999 0 RW Uni US
x.32
CTNet easy mode set-up - Transfer
slot 1 destination parameter
0 to 9,999 0 RW Uni US
x.33
CTNet easy mode set-up - Transfer
slot 2 destination parameter
0 to 9,999 0 RW Uni US
x.34
CTNet easy mode set-up - Transfer
slot 3 destination parameter
0 to 9,999 0 RW Uni US
x.35 CTNet sync event task ID
Disabled (0), Event (1), Event1 (2), Event2 (3),
Event3 (4)
Disabled (0) RW Txt US
x.36 CTNet diagnostic parameter RO Uni NC PT
x.37 Reject download if drive enabled OFF (0) or On (1) OFF (0) RW Bit US
x.38 Do not trip drive on APC run-time error OFF (0) or On (1) OFF (0) RW Bit US
x.39 Inter-module synchronisation status 0 to 3 0 RO Uni NC
x.41 Indexer control 0 to 255 0 RW Uni NC
x.42 Freeze main drive position OFF (0) or On (1) OFF (0) RW Bit US
x.43 Freeze invert OFF (0) or On (1) OFF (0) RW Bit US
x.44 Task priority level 0 to 255 0 RW Uni US
x.45 Indexer step 0 to 65535 RO Uni NC
x.46 Indexer error number -32,768 to =32,767 RO Uni NC
x.47 Indexer state 0 to 255 RO Uni NC
x.48 DPL line number in error 0 to 2,147,483,647 0 RO Uni NC PT
x.49 User program ID -32,767 to +32,768 0 RO Bi NC PT
x.50 Solutions Module error status* 0 to 255 RO Uni NC PT
x.51
Solutions Module software sub-version
0 to 99 RO Uni NC PT
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
