13.15.4 Fieldbus module category
Fieldbus module parameters
*See trip SLX.Er, Fieldbus module category
on page 286
.
Parameter
Range(
Ú) Default(Ö)
Type
x.01 Solutions Module ID 0 to 599 RO Uni PT US
x.02 Solutions Module software version 0.00 to 99.99 RO Uni NC PT
x.03 Fieldbus Node Address 65,535 65,535 RW Uni US
x.04 Fieldbus Baud Rate -128 to +127 0 RW Bi US
x.05 Mode 65,535 4 RW Uni US
x.06 Fieldbus Diagnostic ±9,999 RO Bi NC PT
x.07 Trip Delay Time 0 to 3,000 200 RW Uni US
x.08 Little endianism select OFF (0) or On (1) On (1) RW Bit US
x.09 Register control OFF (0) or On (1) OFF (0) RW Bit US
x.10 to
x.19
‘I’ data registers 0 - 9 -32,768 to +32,767 RW Bi
x.20 to
x.29
‘O’ data registers 0 - 9 -32,768 to +32,767 RW Bi
x.30
Load Solutions Module
defaults
OFF (0) or On (1) OFF (0) RW Bit US
x.31
Save Solutions Module
parameters
OFF (0) or On (1) OFF (0) RW Bit US
x.32 Request to reinitialise OFF (0) or On (1) OFF (0) RW Bit
x.33
Download from Fieldbus
Solutions Module
OFF (0) or On (1) OFF (0) RW Bit
x.34 Compression OFF (0) or On (1) OFF (0) RW Bit US
x.35 Serial number -2,147,483,648 to 2,147,483,647 RO Bi NC PT
x.36 to
x.37
Fieldbus specific OFF (0) or On (1) OFF (0) RW Bit US
x.38
Fieldbus specific defined
mode
0 to 255 0 RW Uni US
x.39 Cyclic input configuration 0 to 255 0 RW Uni US
x.40 Cyclic output configuration 0 to 255 0 RW Uni US
x.41 to
x.43
Fieldbus specific 0 to 255 0 RW Uni US
x.44 to
x.48
Fieldbus specific 0 to 255 0 RO Uni PT
x.49 Mapping error status 0 to 255 0 RO Uni PT
x.50 Solutions Module error status* 0 to 255 RO Uni NC PT
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
