6
WARNING Be sure there is no power connection before starting installation!
2.1 Hard Disk Installation
2.1.1 8 Channel DVR Dual Hard Disk Installation
This type of DVR contains two internal hard drive brackets for installing two SATA hard
drives. You may use one drive only.
Install the hard drive by following these simple steps
Step 1 Unscrew the two screws on either side of the DVR housing. There are four
screws to remove in this step.
Step 2 Slide the top cover slightly backwards and then lift it out.
Step 3 Remove the two screws shown to take off the first hard drive bracket.
To Next Page
