33
3.5.6.1 Channel Number
Select the icon “ ” to setup for all channels at one time.
Select any single icons “ ”, “ ”, “ ”, “ ”, “ ”, “ ”, “ ”, “ ” to individually setup of
each channel.
3.5.6.2 Recording Resolution
Select the recording resolution for each or all channels as:
» D1: 704*480 / 60fps (NTSC); 704*576 / 50fps (PAL)
» Half D1: 704*240 / 120fps (NTSC); 704*288 (PAL) (Default)
» CIF: 352*240 / 120fps (NTSC); 352*288 (PAL)
3.5.6.3 Video Quality
Video image quality settings can be Highest, High, Standard, Low, and Lowest. Default is
Standard.
Higher video quality provides a much clearer image for playback but can utilize a much
larger hard drive space with a larger file size.
3.5.6.4 Record Frame Rate
T he recording frame rate for each or all channels may be set from 0~30 fps.
If the frame rate is set to 0 it means that it will not be recording.
3.5.6.5 Recording Performance Gains
The “Record Performance Gains” enables the system to automatically increase the
system power on the heavy loading channel, taking power from the un-triggered,
unutilized or non- recording channels. This function can apply for one or all channels.
Auto Record [30Sec]
Active Performance Gain [ Enable ]
Record Schedule
Total Frame Rate: 240 / 240 (Power / Sec)
Auto Settings Adjustment
Channel Recording Setup
Channel Number
Record Resolution [Middle Res (Half D1)]
Video Quality [Standard]
Record Frame Rate [15]
Record Performance Gains [ YES]
To Next Page
