3.2.1 S
tate Bar Inform
ation
The
S
tate
Bar displays the status
and notification icons of t
he surveillance system.
Icon
Function
Icon
Function
Camera
is
working
No signal from camera
Recording
Recording Stop
Force Record Start
Network connected
USB disk connected
Network disconnected
Hard drive overwrite enabl
ed
Hard drive status
Channel display rotation enabled
XX%
Percentage of hard drive already us
ed
2010/06/03
Current date
15:37:47
Current time
1%
2010/06/06 15:37:47
1%
2010/06/06 15:37:47
24
