75
4.2 Play Menu
Press “” (or “II”) button or icon to enter Play Menu in the live view window.
Channel Number
Play Begin Time [2010/7/04 10:40:02]
Play End Time [2010/7/14 05:59:13]
2121 ▲ ▲ 2010/07/14 06:18:31
2120 2010/07/14 06:17:12
2119 2010/07/14 05:57:38
2118 2010/07/14 04:20:11
2117 ▼ ▼ 2010/07/14 02:18:42
[ Option] [ Play] [ Backup]
Channel Number: select the channel to playback
Play Begin Time: specify the beginning of the playback
Play End Time: specify the end time of the playback
The information below it shows the available recorded events.
To click [ Option] to switching the window as follows:
2121 ▲ ▲ 2010/07/14 06:18:31
2120 2010/07/14 06:17:12
2119 2010/07/14 05:57:38
2118 2010/07/14 04:20:11
2117 ▼ ▼ 2010/07/14 02:18:42
[ Option] [ Play] [ Backup]
[ Play]: Start playing the recorded data. After the data has been played, it will show
“”
[ Backup]: To back-up the recorded data. Please refer to the “Backup” section
To Next Page
