66
3.10.2 Firmware Update
The firmware is updated by using a USB pen drive that contains the latest firmware file.
With the upgrade firmware file on the root directory of the USB drive, insert the external
USB drive into the USB port of the DVR front panel as shown on the picture below.
Current Revision: V15.0.0
Current Date/Time: Jun 14 2010 05:22:38
Current Language: English
Current Checksum: 0x0332E245
File Name:
File Revision:
File Date/Time:
File Language:
File Checksum:
After the USB disk is attached to the port, the message “Read file Information” will
appear on the bottom line of the screen.
USB Disk [General Flash Disk]
File System [FAT32]
Free Capacity [1005MB]
Total Capacity [1005MB]
To Next Page
Loading...
