multi EA 5000 Specifications
181
Operating range of the wide-range
coulometer
3
measuring cells ¡ "high sensitive"
¡ "sensitive"
¡ "high concentration"
The "high sensitive" measuring
cell
Measurement mode Potentiometry
Measuring range (Cl absolute) 0.01 to 10 µg
Generator current 100 µA
Electrolyte volume 65 ml
The "sensitive" measuring cell
Measurement mode Bi-amperometry
Measuring range (Cl absolute) 1 to 100 µg
Generator current 1 mA
Electrolyte volume 15 to 20 ml
The "high concentration"
measuring cell
Measurement mode Bi-amperometry
Measuring range (Cl absolute) 10 to 1000 µg
Generator current 10 mA
Electrolyte volume 120 ml
Electrical variables
Power supply 110 to 240 V +10/-5 %
Overvoltage category II
Frequency 50/60 Hz
Module fuse protection
Number of device fuses
T 2.0 A H
2
Typical average power consumption 50 VA
Interface to the basic module RS 232
Only use original fuses from Analytik Jena!
General characteristics
Dimensions (W x H x D) 300 x 470 x 530 mm
Mass 12 kg
17.4 Technical data for the UVFD 5000, MPO 5000
Procedural data
Analytical parameters Total sulfur TS
Detection principle UV fluorescence
Measuring range (S in sample) 0.01 to 10000 mg/l S
Measuring range (S absolute) 0 to 100 µg S
MPO option TS determination in the presence of
elevated nitrogen concentrations (only
available with the MPO 5000
)
