multi EA 5000 Function and design
21
1
2
3
4
Figure5 Interfaces on the rear of the device
1 Gas connectors 3 USB port for PC
2 Power connection, power switch 4 Interfaces for detector modules and
sampling modules
1
2
3
Figure6 Power connection, power switch
1 Power switch 2 Equipment fuse
3 Power connection
