multi EA 5000 Function and design
23
1 2 3
Figure9 Connections for the auto-protection valve assembly and transfer line
1 Toggle switch for opening and clos-
ing the pneumatic seal in the auto-
protection valve assembly
2 Transfer line heating connection
3 Valve assembly connection
4.1.2.3 Gas supply/hose diagrams
Hose diagrams
The connection between the individual components is made with labeled hoses. The
numbers circled in the hose diagram match the labels on the hoses in the
multi EA 5000
.
