Page #183 background image
multi EA 5000 Specifications
183
Electrical variables
Power supply 110 to 240 V +10/-5 %
Overvoltage category II
Frequency 50/60 Hz
Module fuse protection
Number of device fuses
T 4.0 A H
2
Typical average power consumption 50 VA
Interface to the basic module RS 232
Only use original fuses from Analytik Jena!
General characteristics
Dimensions (W x H x D) 300 x 470 x 530 mm
Mass 12 kg
17.7 Technical data for the TOC module
Procedural data
Analytical parameters Total carbon TC, TIC, TOC, NPOC, EC/OC
Sample feed for TIC analysis Direct injection in the TIC reactor
Detection principle NDIR (non-dispersive infrared absorption
spectrometry)
Measuring range (C in aqueous samples) 0.2 to 10000 mg/l C
Measuring range (C in organic samples) 0.1 to 10000 mg/l C
Measuring range (C absolute) 0 to 500 mg C
Electrical variables
Power supply 110 to 240 V +10/-5 %
Overvoltage category II
Frequency 50/60 Hz
Module fuse protection
Number of device fuses
T 4.0 A H
2
Typical average power consumption 50 VA
Interface to the basic module RS 232
Only use original fuses from Analytik Jena!
General characteristics
Dimensions (W x H x D) 300 x 470 x 530 mm
Mass 12 kg
