Technical data Proline Promag 53 MODBUS RS485
126 Endress+Hauser
Promag P
!
Note!
The following weights apply to standard pressure ratings and without packaging material.
Promag H
!
Note!
The following weights apply to standard pressure ratings and without packaging material.
Nominal
diameter
Weights in [kg] for the Promag P
Compact version Remote version (without cable)
Sensor Transmitter
[mm] EN (DIN) / AS* JIS EN (DIN) / AS* JIS
15
PN 40
6.5
10K
6.5
PN 40
4.5
10K
4.5 6.0
25 7.3 7.3 5.3 5.3 6.0
32 8.0 7.3 6.0 5.3 6.0
40 9.4 8.3 7.4 6.3 6.0
50 10.6 9.3 8.6 7.3 6.0
65
PN 16
12.0 11.1
PN 16
10.0 9.1 6.0
80 14.0 12.5 12.0 10.5 6.0
100 14.4 14.7 14.0 12.7 6.0
125 16.0 21.0 19.5 19.0 6.0
150 21.5 24.5 23.5 22.5 6.0
200
PN 10
45 41.9
PN 10
43 39.9 6.0
250 65 69.4 63 67.4 6.0
300 70 72.3 68 70.3 6.0
350 115 113 6.0
400 135 133 6.0
450 175 173 6.0
500 175 173 6.0
600 235 233 6.0
Promag transmitter (compact version): 3.4 kg
High-temperature version: +1.5 kg
* Only DN 25 and 50 are available for flanges as per AS
Nominal
diameter
Weights in [kg] for the Promag H
DIN Compact version Remote version (without cable)
[mm] Sensor Transmitter
2 5.2 2.0 6.0
4 5.2 2.0 6.0
8 5.3 2.0 6.0
15 5.4 1.9 6.0
25 5.5 2.8 6.0
40 6.5 4.5 6.0
50 9.0 7.0 6.0
65 9.5 7.5 6.0
80 19.0 17.0 6.0
100 18.5 16.5 6.0
Promag transmitter (compact version): 3.4 kg
