6 Commissioning
6.1 Function check
Make sure that all final checks have been completed before you start up your measuring point:
• Checklist for "Post-installation check" → ä 39
• Checklist for "Post-connection check" → ä 52
6.2 Switching on the measuring device
Once the post-connection checks have been successfully completed, it is time to switch on the
supply voltage. The device is now operational.
The measuring device performs a number of post switch-on self-tests. As this procedure progresses
the following sequence of messages appears on the local display:
Normal measuring mode commences as soon as startup completes.
Various measured-value and/or status variables (HOME position) appear on the display.
!
Note!
If startup fails, an error message indicating the cause is displayed.
PROMAG 53
START-UP
RUNNING
Start-up message
▼
PROMAG 53
DEVICE SOFTWARE
V XX.XX.XX
Current software version
▼
MODBUS RS485
RELAY OUTPUT 1
RELAY OUTPUT 2
STATUS INPUT 1
List of installed input/output modules
▼
SYSTEM OK
→ MEASURING
OPERATION
Beginning of normal measuring mode
▼
