Proline Promag 53 MODBUS RS485 Technical data
Endress+Hauser 125
10.1.10 Mechanical construction
Design / dimensions The dimensions and face-to-face length of the sensor and transmitter can be found in the separate
"Technical Information" documentation for each device which can be downloaded in PDF format
from www.endress.com. A list of available "Technical Information" documentation can be found in
the "Documentation" → ä 134 section.
Weight (SI units) Promag W
!
Note!
The following weights apply to standard pressure ratings and without packaging material.
Nominal
diameter
Weights in [kg] for the Promag W
Compact version Remote version (without cable)
Sensor Transmitter
[mm] EN (DIN) / AS* JIS EN (DIN) / AS* JIS
25
PN 40
7.3
10K
7.3
PN 40
5.3
10K
5.3 6.0
32 8.0 7.3 6.0 5.3 6.0
40 9.4 8.3 7.4 6.3 6.0
50 10.6 9.3 8.6 7.3 6.0
65
PN 16
12.0 11.1
PN 16
10.0 9.1 6.0
80 14.0 12.5 12.0 10.5 6.0
100 16.0 14.7 14.0 12.7 6.0
125 21.5 21.0 19.5 19.0 6.0
150 25.5 24.5 23.5 22.5 6.0
200
PN 10
45 41.9
PN 10
43 39.9 6.0
250 65 69.4 63 67.4 6.0
300 70 72.3 68 70.3 6.0
350 115 113 6.0
375 134 133 6.0
400 135 133 6.0
450 175 173 6.0
500 175 173 6.0
600 235 233 6.0
700 355 353 6.0
800 435 433 6.0
900 575 573 6.0
1000 700 698 6.0
1200
PN 6
850
PN 6
848 6.0
1400 1300 1298 6.0
1600 1700 1698 6.0
1800 2200 2198 6.0
2000
2800 2798 6.0
Promag transmitter (compact version): 3.4 kg
*Only DN 80, 100, 150 to 400, 500 and 600 are available for flanges as per AS
