Proline Promag 53 MODBUS RS485 Commissioning
Endress+Hauser 87
Recommended settings
Quick Setup "Batching"
HOME position → F → MEASURAND → O → QUICK SETUP → N → QUICK SETUP BATCHING (1005)
Function No. Function name Setting to be selected ( P )
(to the next function with F )
1005 QUICK SETUP BATCHING YES
After F is pressed by way of confirmation, the
Quick Setup menu calls up all the subsequent
functions in succession.
▼
!
Note!
Some of the functions listed below (with a gray background) are configured automatically, i.e. by the measuring system.
6400 ASSIGN LOW FLOW CUT OFF VOLUME FLOW
6402 ON-VALUE LOW FLOW CUT OFF The recommended setting can be found on
→ ä 84 in Function No. 6402.
6403 OFF-VALUE LOW FLOW CUT OFF 50%
6603 SYSTEM DAMPING 9
!
Note!
The parameter has to be optimized for highly
accurate and short filling processes: to do this, put
the setting to "0".
6404 PRESSURE SHOCK SUPPRESSION 0 s
7200 BATCH SELECTOR BATCH #1
7201 BATCH NAME BATCH #1
7202 ASSIGN BATCH VARIABLE VOLUME
7203 BATCH QUANTITY 0
7204 FIX COMPENSATION QUANTITY 0
7208 BATCH STAGES 1
7209 INPUT FORMAT Value input
4700 ASSIGN RELAY BATCHING VALVE 1
4780 TERMINAL NUMBER Output (display only)
7220 OPEN VALVE 1 0% or 0 [unit]
7240 MAXIMUM BATCH TIME 0 s (= switched off)
7241 MINIMUM BATCH QUANTITY 0
7242 MAXIMUM BATCH QUANTITY 0
2200 ASSIGN (Main line) BATCH NAME
2220 ASSIGN (Multiplex main line) Off
2400 ASSIGN (Additional line) BATCH DOWNWARDS
2420 ASSIGN (Multiplex additional line) Off
2600 ASSIGN (Information line) BATCHING KEYS
2620 ASSIGN (Multiplex information line) Off
▼
Back to the HOME position:
→ Press and hold down the X key for longer than three seconds or
→ Repeatedly press and release the X key → Exit the function matrix step by step
