Recommended flow (US units)
Nominal diameter Promag W Promag P Promag H
[inch] Min./max. full scale value (v ≈ 0.3 or 10 m/s) in [gal/min]
1
1
/
12
" – – 0.015 to 0.5
5
/
32
"– –0.07 to 2
5
/
16
"– –0.25 to 8
1
/
2
" – 1.0 to 27 1.0 to 27
1" 2.5 to 80 2.5 to 80 2.5 to 80
1
1
/
4
" 4 to 130 4 to 130 –
1
1
/
2
" 7 to 190 7 to 190 7 to 190
2" 10 to 300 10 to 300 10 to 300
2
1
/
2
" 16 to 500 16 to 500 16 to 500
3" 24 to 800 24 to 800 24 to 800
4" 40 to 1250 40 to 1250 40 to 1250
5" 60 to 1950 60 to 1950 –
6" 90 to 2650 90 to 2650 –
8" 155 to 4850 155 to 4850 –
10" 250 to 7500 250 to 7500 –
12" 350 to 10600 350 to 10600 –
14" 500 to 15000 500 to 15000 –
15" 600 to 19000 – –
16" 600 to 19000 600 to 19000 –
18" 800 to 24000 800 to 24000 –
20" 1000 to 30000 1000 to 30000 –
24" 1400 to 44000 1400 to 44000 –
28" 1900 to 60000 – –
30" 2150 to 67000 – –
32" 2450 to 80000 – –
36" 3100 to 100000 – –
40" 3800 to 125000 – –
42" 4200 to 135000 – –
48" 5500 to 175000 – –
[inch] Min./max. full scale value (v ≈ 0.3 or 10 m/s) in [Mgal/d]
54" 9 to 300 – –
60" 12 to 380 – –
66" 14 to 500 – –
72" 16 to 570 – –
78" 18 to 650 – –
