Installation Proline Promag 53 MODBUS RS485
26 Endress+Hauser
Promag W tightening torques for AS 4087
Sensor
Nominal diameter
AS 4087
Pressure rating
Screws Max. tightening torque [Nm]
[mm] Hard rubber
80 PN 16 4 × M 16 49
100 * PN 16 8 × M 16 38
150 PN 16 8 × M 20 52
200 PN 16 8 × M 20 77
250 PN 16 8 × M 20 147
300 PN 16 12 × M 24 103
350 PN 16 12 × M 24 203
375 PN 16 12 × M 24 137
400 PN 16 12 × M 24 226
500 PN 16 16 × M 24 271
600 PN 16 16 × M 30 393
700 PN 16 20 × M 27 330
750 PN 16 20 × M 30 529
800 PN 16 20 × M 33 631
900 PN 16 24 × M 33 627
1000 PN 16 24 × M 33 595
1200 PN 16 32 × M 33 703
* Designed acc. to AS 2129 (not to AS 4087)
