Promag P tightening torques for AS 2129
Promag P tightening torques for AS 4087
150 10K 8 × M 20 99 81
150 20K 12 × M 22 108 72
200 10K 12 × M 20 82 54
200 20K 12 × M 22 121 88
250 10K 12 × M 22 133 –
250 20K 12 × M 24 212 –
300 10K 16 × M 22 99 –
300 20K 16 × M 24 183 –
Nominal diameter
[mm]
AS 2129
Pressure rating
Screws Max. tightening torque [Nm]
PTFE
25 Table E 4 × M 12 21
50 Table E 4 × M 16 42
Nominal diameter
[mm]
AS 4087
Pressure rating
Screws Max. tightening torque [Nm]
PTFE
50 PN 16 4 × M 16 42
Nominal diameter JIS
Pressure rating
Screws Max. tightening torque [Nm]
[mm] PTFE PFA
