Troubleshooting Proline Promag 53 MODBUS RS485
98 Endress+Hauser
13 TRANSM.
HW-DAT
041 S: TRANSM. HW-DAT
$: # 041
Transmitter DAT:
1. T-DAT is defective.
2. T-DAT is not plugged into
the amplifier board or is
missing.
1. Check whether the T-DAT is correctly plugged
into the amplifier board.
2. Replace the T-DAT if it is defective.
Check that the new replacement DAT is
compatible with the measuring electronics.
Check the:
– Spare part set number
– Hardware revision code
3. Replace measuring electronics boards if
necessary.
4. Plug the T-DAT into the amplifier board.
14 TRANSM.
SW-DAT
042 S: TRANSM. SW-DAT
$: # 042
Transmitter:
Error accessing the adjustment
values stored in the T-DAT.
115 HW F-CHIP 061 S: HW F-CHIP
$: # 061
Transmitter F-Chip:
1. F-Chip is defective.
2. F-CHIP is not plugged
into the
I/O board or is missing.
1. Replace the F-CHIP.
2. Plug the F-CHIP into the I/O board
No. # 1xx → Software error
19 GAIN ERROR AMP 101 S: GAIN ERROR AMP
$: # 101
Gain deviation compared to
reference gain is greater than
2%.
Replace amplifier board.
114 A/C SW COMPATIB. 121 S: A / C COMPATIB.
!: # 121
Due to different software
versions, I/O board and
amplifier board are only
partially compatible (possibly
restricted functionality).
!
Note!
– The indication on the
display as notice message
appears only for 30 seconds
(with listing in "Previous
system condition"
function).
– This condition can occur if
only one electronics board
has been exchanged; the
extended software
functionality is not
available. The previously
existing software
functionality is still working
and the measurement
possible.
Module with lower software version has either to
be updated by "FieldCare" with the required
software version or the module has to be replaced.
No. # 2xx → Error in DAT/no communication
22 LOAD T-DAT 205 S: LOAD T-DAT
!: # 205
Transmitter DAT:
Data back-up (downloading)
to T-DAT failed
or
Error when accessing
(uploading) the values stored
in the T-DAT.
1. Check whether the T-DAT is correctly plugged
into the amplifier board.
2. Replace the T-DAT if it is defective.
Before replacing the DAT, check that the new,
replacement DAT is compatible with the
measuring electronics. Check the:
– Spare part set number
– Hardware revision code
3. Replace measuring electronics boards if
necessary.
23 SAVE T-DAT 206 S: SAVE T-DAT
!: # 206
MODBUS No. Device status message
(local display)
Cause Remedy (spare part → ä 107)
Register:
6859
Data type:
Integer
Register:
6821
Data type:
String (18 byte)
