Enterasys Matrix E1 1H582-51 - Port Numbering Scheme with Expansion Modules Installed

Port Designations in WebView
Starting and Navigating WebView 2-9
Table 2-2 Port Numbering Scheme with Expansion Modules Installed
Port/Module Type Slot Location Port Numbering Sequence
Fixed Front Panel
Forty-eight fixed RJ45 ports
Fast Ethernet
10/100BASE-TX
Front panel | 1 | 3 | 5 | 7 | 9 | 11 | 13 | 15 |
| 2 | 4 | 6 | 8 | 10 | 12 | 14 | 16 |
| 17 | 19 | 21 | 23 | 25 | 27 | 29 | 31 |
| 18 | 20 | 22 | 24 | 26 | 28 | 30 | 32 |
| 33 | 35 | 37 | 39 | 41 | 43 | 45 | 47 |
| 34 | 36 | 38 | 40 | 42 | 44 | 46 | 48 |
1H-16TX Expansion Module
Sixteen fixed RJ45 ports
Fast Ethernet
10/100BASE-TX
Installed in Slot 1 | 49 | 51 | 53 | 55 | 57 | 59 | 61 | 63 |
| 50 | 52 | 54 | 56 | 58 | 60 | 62 | 64 |
Installed in Slot 2 | 65 | 67 | 69 | 71 | 73 | 75 | 77 | 79 |
| 66 | 68 | 70 | 72 | 74 | 76 | 78 | 80 |
Installed in Slot 3 | 81 | 83 | 85 | 87 | 89 | 91 | 93 | 95 |
| 82 | 84 | 86 | 88 | 90 | 92 | 94 | 96 |
1G-2TX Expansion Module
Two fixed RJ45 ports
Fast Ethernet
1000BASE-TX
Installed in Slot 1 | 49 | 57 |
Installed in Slot 2 | 65 | 73 |
Installed in Slot 3 | 81 | 89 |
1G-2GBIC Expansion
Module
Two port slots for optional
GBICs
Gigabit 1000BASE-SX/LX
Installed in Slot 1 | 49 | 57 |
Installed in Slot 2 | 65 | 73 |
Installed in Slot 3 | 81 | 89 |
