Port Advertised Ability Configuration Screen
WebView Local Management Tasks 3-53
Screen Element Descriptions
Refer to Table 3-28 for a functional description of each screen element.
Table 3-28 Port Advertised Ability Configuration Screen Element Descriptions
Use this field… To…
Port See the port number associated with the displayed status information.
Adv 10M Set the Port to advertise (or not) 10M Half-Duplex and/or 10M
Full-Duplex.
Adv 100M Set the Port to advertise (or not) 100M Half-Duplex and/or 100M
Full-Duplex.
Adv 1G For Ports that support Gigabit Ethernet, set the Port to advertise (or
not) 1G Half-Duplex and/or 1G Full-Duplex.
Adv Flow Ctrl Set the Port to advertise (or not) Flow Control.
