VLAN Basic Information Screen
3-34 WebView Local Management Tasks
Screen Element Descriptions
Refer to Table 3-17 for a functional description of each screen element.
3.19 VLAN BASIC INFORMATION SCREEN
When to Use
To view basic information about the numbers of VLANs configured on the device, and to access
the VLAN Current Table, VLAN Static List, VLAN Static Table, VLAN Static Membership by
Port, and VLAN Port Configuration screens.
How to Access
Click on VLAN on the WebView navigation frame. The VLAN Basic Information screen,
Figure 3-18, displays.
Table 3-17 Port Traffic Class Information Screen Element Descriptions
Use this field… To…
Port See the port number associated with the displayed priority parameters.
Priority <0 - 7> See the traffic class, or transmit queue, associated with priority levels 0
through 7 for each port. 0 indicates that the priority has been assigned
the lowest transmit queue priority, and 3 indicates it has been assigned
the highest. For example, as shown in Figure 3-17, if the port priority
queue is set to 3 for frames with a port priority 7, then those frames
would be transmitted before any frames contained in traffic classes 2
through 0.
Class Range See the range of egress traffic classes available for each port. 0-3
indicates there are 4 traffic classes available.
