3.22 VLAN STATIC TABLE SCREEN
When to Use
To configure a static VLAN’s egress list, including which ports belong to the list, which ports can
transmit untagged frames, and which are forbidden ports.
How to Access
Click on VLAN on the WebView navigation frame. The VLAN Basic Information screen,
Figure 3-18, displays. Click on VLAN Static Table on the content frame. The VLAN Static Table
screen, Figure 3-21, displays.
Table 3-20 VLAN Static List Screen Element Descriptions
Use this field or button… To…
Current See the ID number(s) for currently configured VLANs and
whether or not they are enabled or disabled.
VLAN ID (1-4094) Enter a unique number (1 to 4094) for the new VLAN to be
created.
VLAN Name Enter a name (1 to 32 characters) for the new or previously
created static VLAN.
Status Enable or Disable the static VLAN.
Add the new static VLAN to the list of those recognized by the
device.
Remove a selected entry from the device’s VLAN list. To select
an entry click on it in the Current field.
Remove all entries from the device’s VLAN list.
To Next Page
