VLAN Current Table Screen
WebView Local Management Tasks 3-37
Screen Element Descriptions
Refer to Table 3-19 for a functional description of each screen element.
Table 3-19 VLAN Current Table Screen Element Descriptions
Use this field… To…
VLAN Entry Delete
Count
See the number of times a VLAN entry has been deleted from this
table.
VLAN ID Select the number identifying the VLAN for which to see port egress
information. Default is 1.
Egress Ports See which ports belong to the VLAN’s egress list.
Untagged Ports See which ports belonging to the VLAN are configured to transmit
untagged frames.
