Port Admin/Negotiation Configuration Screen
WebView Local Management Tasks 3-51
Screen Element Descriptions
Refer to Table 3-27 for a functional description of each screen element.
Table 3-27 Port Admin/Negotiation Configuration Screen Element Descriptions
Use this field… To…
Flow control mode Enable All or Disable All ports for flow control mode (only effects
ports that have auto-negotiation disabled).
Port See the port number associated with the displayed status information.
Admin Status Administratively Enable or Disable the port.
Auto Negotiate Enable or Disable Auto Negotiation on a Port by Port basis.
Speed/Duplex
Config
Set the port’s duplex mode. Options are: 10M Half-Duplex, 10M
Full-Duplex, 100M Half-Duplex, and 100M Full-Duplex.
Note: This option is only available when Auto-Negotiation is disabled.
Flow Control
Config
Set the port’s flow control status (Enabled or Disabled). Flow control
is used to manage the transmission between two devices as specified
by IEEE 802.3x to prevent receiving ports from being overwhelmed by
frames from transmitting devices.
Note: This option is only available when Auto-Negotiation is disabled.
