Port Information Screen
WebView Local Management Tasks 3-49
Screen Element Descriptions
Refer to Table 3-26 for a functional description of each screen element.
Table 3-26 Port Information Screen Element Descriptions
Use this field… To…
Port See the port number associated with the displayed status information.
Admin Status See whether the port is administratively Enabled (up) or Disabled
(down).
Link Status See whether the port has a valid link (Up or Down). Link status will be
down until a link is established to an external device and the port is
enabled.
Speed Status See the port’s operational speed in Mbps (10M, 100M or 1000M).
Duplex Status See the port’s duplex mode. Options are: 10M Half-Duplex, 10M
Full-Duplex, 100M Half-Duplex, 100M Full-Duplex, and
Auto-Negotiation.
Flow Control Status See the port’s flow control status Enabled, Disabled, or N/A
(Auto-Negotiate is enabled). Flow control is used to manage the
transmission between two devices as specified by IEEE 802.3x to
prevent receiving ports from being overwhelmed by frames from
transmitting devices.
