VLAN Static Membership by Port Screen
3-42 WebView Local Management Tasks
3.23 VLAN STATIC MEMBERSHIP BY PORT SCREEN
When to Use
To add ports to or remove ports from a static VLAN. Static VLANs are those created by the user
using the CLI or the fields in the VLAN configuration screens.
How to Access
Click on VLAN on the WebView navigation frame. The VLAN Basic Information screen,
Figure 3-18, displays. Click on VLAN Static Membership by Port on the content frame. The
VLAN Static Membership by Port screen, Figure 3-22, displays.
Screen Example
Figure 3-22 VLAN Static Membership by Port Screen
Non-Members See which ports are not configured to transmit untagged frames
for a static VLAN.
Make a selected Non-Member port part of the Member list of
ports able to transmit untagged frames for the static VLAN.
Make a selected Member port part of the Non-Member egress
list of ports not able to transmit untagged frames for the static
VLAN.
Table 3-21 VLAN Static Table Screen Element Descriptions (Continued)
Use this field or button… To…
