IP Multicast Registration Table Screen
3-46 WebView Local Management Tasks
3.26 IP MULTICAST REGISTRATION TABLE SCREEN
When to Use
To view the status of IGMP groups on the device. This includes the VLAN port configured to
transmit IGMP multicast transmissions, its VLAN ID, and the IP addresses of the ports asking to
receive those transmissions as part of the IGMP group.
How to Access
Click on IGMP on the WebView navigation frame. The IGMP Configuration screen, Figure 3-24,
displays. Click on IP Multicast Registration Table on the content frame. The IP Multicast
Registration Table screen, Figure 3-25, displays.
Screen Example
Figure 3-25 IP Multicast Registration Table Screen
