VLAN Port Configuration Screen
WebView Local Management Tasks 3-43
Screen Element Descriptions
Refer to Table 3-22 for a functional description of each screen element.
3.24 VLAN PORT CONFIGURATION SCREEN
When to Use
To assign default VLAN IDs to untagged frames, and to enable or disable ingress filtering on one
or more ports.
How to Access
Click on VLAN on the WebView navigation frame. The VLAN Basic Information screen,
Figure 3-18, displays. Click on VLAN Port Configuration on the content frame. The VLAN
Configuration screen, Figure 3-23, displays.
Table 3-22 VLAN Static Membership by Port Screen Element Descriptions
Use this field or button… To…
Port Number Select the number of the port for which to configure VLAN
membership.
Member See the number and name of the VLAN of which the port is a
member.
Non-Member See the number and name of the VLAN of which the port is not a
member.
Make the port a Member of the selected static VLAN.
Make the port a Non-Member of the selected static VLAN.
To Next Page
