Address Table Configuration Screen
WebView Local Management Tasks 3-13
Table 3-8 Address Table Configuration Screen Element Descriptions
Use this field or button… To…
Address Table See the device’s current address table entries.
MAC Address Enter a MAC address for a new static address table entry.
VLAN (1-4094) Enter a number (1 to 4094) identifying the VLAN to which the
MAC address belongs.
Port Select a port number associated with the MAC Address and
VLAN.
Status Select a status for new static address entries. Valid options are:
Permanent - Leaves all addresses in the address table, even if
the device is reset.
Delete on Reset - Deletes all new static addresses when the
device is reset.
Delete on Timeout - Deletes all new static addresses when the
device times out.
Add the new static address entry to the address table.
Remove a selected entry from the address table. To select an
entry, click on it in the Address Table field.
Clear all entries in the device’s address table.
Aging Time (10-630): Enter a timeout period (from 10 to 630 seconds) for aging out all
dynamically learned MAC addresses and forwarding
information.
Dynamic Address
Counts:
See the number of dynamic addresses in the device’s address
table.
Static Address Counts: See the number of static addresses in the device’s address table.
Static addresses are those created by the user using the CLI or the
fields in this screen.
