Port Statistics Screen
WebView Local Management Tasks 3-61
Jabbers See the total number of frames that were greater than 1518 bytes
and had either a bad FCS or a bad CRC.
Collisions See the total number of collisions that have occurred on this
interface.
64 Bytes Frames See the total number of frames, including bad frames, received
that were 64 bytes in length (excluding framing bits, but
including FCS bytes).
65 – 127 Bytes Frames See the total number of frames, including bad frames, received
that were between 65 and 127 bytes in length (excluding framing
bits, but including FCS bytes).
128 – 255 Bytes Frames See the total number of frames, including bad frames, received
that were between 128 and 255 bytes in length (excluding
framing bits, but including FCS bytes).
256 – 511 Bytes Frames See the total number of frames, including bad frames, received
that were between 256 and 511 bytes in length (excluding
framing bits, but including FCS bytes).
512 – 1023 Bytes Frames See the total number of frames, including bad frames, received
that were between 512 and 1023 bytes in length (excluding
framing bits, but including FCS bytes).
1024 – 1532 Bytes Frames See the total number of frames, including bad frames, received
that were between 1024 and 1532 bytes in length (excluding
framing bits, but including FCS bytes).
Refresh the Port Statistics screen.
Table 3-31 Port Statistics Screen Element Descriptions (Continued)
Use this field or button… To…
