Epson LX-810 User Guide

Pull Tractor
Paper handling
1. Pull the paper release lever to the continuous paper position;
then turn on the printer.
2. Position the push tractor’s left sprocket unit about 6 mm (l/4
inch) from the far left position and lock it into place. Then
load continuous paper onto the push tractor as described in
Chapter 2.
3. Press the LOAD/EJECT button to load the continuous paper.
Then press the FORM FEED button to advance the paper one
page for fitting onto the pull tractor.
l
CAUTION: If you use the platen knob to feed the paper,
the printer loses track of the top-of-form position. Be
sure to press the LINE FEED or FORM FEED button to feed
paper.
4. Open the pull tractor sprocket covers and release the sprocket
units by pulling the sprocket locks forward.
5. Adjust the sprocket units to match the width of the paper;
then position the paper support midway between the two
sprocket units.
6. Fit the holes of the paper over the tractor pins of the sprocket
units, and then close the sprocket covers.
4-10 Using the Printer Options

Epson LX-810 Specifications

General

Print Method	Impact dot matrix
Number of Pins	9
Character Sets	96 characters (USASCII)
Line Spacing	1/6 inch
Paper Path	Rear
Interface	Centronics parallel
Noise Level	55 dB (A)
