Epson RC700 Series

Installation 2. Installation
8 RC700 Series Rev.3
RS
How to transfer
: Stabilize the Manipulator with your hands and lift the
belt through the eyebolt and carry it.
Where to hold : Under the arm 1 and bottom of the base *(shade part)
* When hold bottom of the base, be careful not
caught your hands or fingers.
Minimum number of people
: 2 people
Do not hold
: -
C4
Where to hold
: The part other than the part that is should not touch
Minimum number of people
: 2 people
Do not hold
: Bottom of the base (slashed part)
C8
Where to hold
: The part other than the part that is should not touch
Minimum number of people
: 2 people
Do not hold
: Bottom of the base (slashed part)
Figure: C8-A901* (C8L)
