Installation 4. First Step
64 RC700 Series Rev.3
4.2.4 Backup the initial condition of the Controller
Backup the Controller data configured before shipment.
Project and system configuration backup procedure:
(1) From the [Project] menu, select [Copy].
(2) Change the [Destination Drive] to an arbitrary drive.
(3) Click <OK>. The project will be copied to the external media.
(4) From the [Tools] menu, select [Controller].
(5) Click on the <Backup Controller> button.
(6) Select the arbitrary drive.
(7) Click <OK>. The system configuration will be backed up on the external media.
4.2.5 Disconnection of Development PC and Controller
Disconnection of the development PC and the Controller is indicated.
(1) Select the EPSON RC+ 7.0 menu-[Setup]-[PC to Controller Communications] to
display the [PC to Controller Communications] dialog box.
(2) Click the <Disconnect> button.
Controller and the development PC is disconnected and USB cable can be removed.
If the USB cable is removed while the Controller and the development PC are connected,
the Manipulator stops. Be sure to click the <Disconnect> button in the [PC to Controller
Communications] dialog box before removing the USB cable.
4.2.6 Moving the Robot to Initial Position
Robot can be operated by the following methods other than creating and executing the
program.
Manual operation
Jog motion by the Teach Pendant
Command execution from the EPSON RC+
Jog motion from the EPSON RC+
This section explains about following methods.
A: Manual operation
B: Command execution from the EPSON RC+
C: Jog motion from the EPSON RC+
A: Manual operation
Move the non-excited robot manually.
For SCARA robot:
Manipulators can be moved manually by pressing the brake release switch when the
brake release unit is connected.
For details, refer to Brake Release Unit in each Manipulator manual.
To Next Page
