Appendix D-30 Product Overview Rev. A
Confidential
The electrical pulse width, paper feed rate, thermistor detection temperature, head supply
voltage, and condition for printing the previous dot are set to the ideal values, depending on the
printing pattern.
Figure D-38
R512
0123
R256
R1
R257
32 Bit cut 32 Bit cut
V
H
DATA IN 1
DATA IN 2
LATCH
CLOCK
STROBE 2
STROBE 1
GND
V
DD
THERMISTOR
THERMISTOR
R512
Data transmission direction ïïïïï
R1
