Epson TM-H6000III Technical Reference Guide

6-2 Application Development Information for APD Rev. C
6.2 Bitmap Printing
There are three methods of printing bitmaps. Use the one appropriate to your purpose.
6.2.1 Explanation of Bitmap Printing
1. Normal Bit-image
The PrintBitmap method is to directly print the bitmap. One bitmap printed by this method
is formed as a combination of “n” numbers of 1-line bitmaps. So, the width of the paper sets
the limit on the size of bitmap, and printing is slow. But the height of paper doesn’t set the
limit on the size of bitmap.
This printer prints Windows fonts by this method.
2. NV Bit-image
EPSON provides a tool, “TMFLogo” that enables registration of a bitmap image in the
NVRAM of an EPSON TM series printer. A bitmap image in the NVRAM can be printed
with a “control font” method.
Function list
The available NVRAM size for the TM-H6000III:
❏ ANK model: max. 384KB
❏ Multilingual model: max. 192KB
Printable Size
Printing Quality
Printing method
Printing Speed. 2 Color Printing Receipt / Slip Printing Printing Position
Note
Normal Bit-image
<width>
Less than paper width.
<height>
no limitation
Normal
Store
No need.
- Available Available Select parameter
When printing
a different
bitmap each
time, this
method is
suitable.
Print
The bitmap data is sent to TM from PC
directly. Refer to the sample program of
APD for detail.
Slow
NV Bit-image
<width>
Less than paper width.
<height>
There is a limitation
Height length
= RAM Size / width length
High level
Store
Store bitmap to NVRAM by TMFLogo
utility. If store the bitmap in a NVRAM at
once, it is not necessary to restore unless
the NVRAM is deleted.
- Available Available Select parameter
When printing
a stored
bitmap that is
always used,
this method is
suitable..
(e.g. a shop
logo)
Print
Print stored bitmap by using “Control
font.” Refer the User’s Manual for detail.
Fast

Epson TM-H6000III Specifications

General

Dimensions (WxDxH)	186 x 298 x 185 mm
USB port	Yes
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Connectivity technology	Wired
Type	POS printer
Print speed	63 lps
Character size	0.99 x 2.4 mm
Print technology	Dot matrix
Safety	UL, CSA, TÜV
Certification	VCC1, FCC, CE
Country of origin	China
Autocutter durability	1.5 million cuts
Mean time between failures (MTBF)	360000 h
Product color	Black
Maximum roll diameter	83 mm
Supported paper width	80 mm
Printing media thickness	60 - 90 µm
Ethernet LAN	No
Input current	1.8 A
Power supply type	DC
Pallet width	800 mm
Pallet height	1675 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	40 pc(s)
Quantity per pallet (UK)	50 pc(s)
Quantity per pallet layer	8 pc(s)
Quantity per pallet layer (UK)	10 pc(s)
Package depth	382 mm
Package width	285 mm
Package height	305 mm
Package weight	6600 g
Quantity per pack	1 pc(s)
