B-2 Power Supply Specifications Rev. C
B.1.2 Case Specifications
❏ Size: 68 mm (D) × 136 mm (L) × 32 mm (H) (excluding
projections) Refer to the figure below.
❏ Mass: Approx. 0.4 kg (excluding the AC cable)
❏ Material: Flame-resistance grade: V0
❏ Color: Black (mat)
Case specifications
Material
No specific brominated flame retardants such as PBBE, PBB are used in this product.
B.1.3 AC Cable Selection
❏ Select an AC cable that satisfies the following conditions.
•Safety Standard product
• Plug with P.E terminal
❏ Ground connection: Ground certainly for safety.
136
68
32
