1-22 General Information Rev. C
1.6 Other Specifications
1.6.1 Internal Buffer
1. Receive buffer selectable as 45 or 4 KB using the DIP switch.
2. User-defined buffer (both for user-defined characters and user-defined bit images)
Receipt: 12KB; Slip: Approximately 3KB
3. Macro buffer 2KB
4. NV (non-volatile) bit image buffer 384KB
5. NV (non-volatile) user memory 1KB
1.6.2 Electrical Characteristics
Note:
The current consumption is as follows when a receipt is printed in low temperature. Take in consideration
if a power supply other than the Epson specified one is used or the print pattern is different.
❏ The values in the table above are measured in the following conditions, but are just for your
reference.
❏ The Epson original power supply PS-180 can print within the print duty above.
Supply voltage: +24 VDC
± 10% (optional power supply: EPSON PS-180)
Ripple voltage: 300 mVpp or less
(only when the printer is used with the MICR reader)
Current consumption (at
24V except for drawer
kickout driving):
Slip: Operating:
Mean: Approximately 1.7A
(Character font A α-N, all columns printing)
Peak: Approximately 5.5A
Receipt: Operating:
Mean: Approximately 1.8A
(Character font A α-N, all columns printing)
Peak: Approximately 7.7A
Standby:
Mean: Approximately 0.2A
Print pattern See figure ’A’ below See figure ’B’ below See figure ’C’ below
Print duty 18% (Alphanumeric
in full column)
50% 100%
Current value (A) at
5C
°
Peak Mean Peak Mean Peak Mean
7.7 1.8 8.5 3.5 9.5 5.0
