Rev. C Power Supply Specifications B-1
TM-H6000III Technical Reference Guide
Appendix B
Power Supply Specifications
This appendix describes the optional power supply unit (PS-180).
B.1 PS-180 (Energy Saving Power Supply Unit)
B.1.1 Electrical Characteristics
❏ Input conditions
Input voltage (rating): 90 to 264VAC
(100 VAC -10% to 230 VAC +15%)
Frequency (rating): 47 Hz to 63 Hz
Input current (rating): 100VA
AC switch None
LED None
❏ Output conditions
Output voltage (rating): 24 VDC ± 5%
Output current (rating): 2.0 A
Output electric power (rating): 48 W
Output peak current: 4.5 A (within 300ms on 1/6 duty)
