Epson TM-H6000III Technical Reference Guide

1-6 General Information Rev. C
2. Notes on slip/validation paper
• The paper must be flat, without curls or wrinkles, especially at the top edges.
Otherwise, the paper may rub against the ribbon and become dirty.
• Insert a validation from the upper side in the validation entrance of the case opening. If
the validation is inserted sliding from the left to the right, the print position may be
incorrect since the paper can be crooked or the validation sensor can detect incorrectly.
• There must be no glue on the bottom edge of paper. Choose paper carefully when the
glue is on the right or top edge, since paper feeding and insertion are affected by gluing
conditions (e.g., glue quality, method, and length) and glue location (refer to the figure
below). Be especially careful when paper is wide and has the glue on the left edge, since
skew may occur.
Slip (validation) paper glued area
• Since the slip BOF sensor uses a photo sensor, do not use paper that has holes at the
sensor position, or is translucent.
• Since the slip TOF sensor and validation sensor use a reflective photo sensor and it
detects from the back of slip paper, do not use paper that has holes or dark portions with
low reflection (less than 40% reflection) at the sensor position.
• Since the slip paper ejection sensor uses a reflective photo sensor and it detects from the
surface of the paper roll, do not use paper that has holes or dark portions with low
reflection (less than 40% reflection) at the sensor position.
Paper feed
direction
Glued area
Use carefullyUse carefullyDo not use
OK to use

Epson TM-H6000III Specifications

General

Dimensions (WxDxH)	186 x 298 x 185 mm
USB port	Yes
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Connectivity technology	Wired
Type	POS printer
Print speed	63 lps
Character size	0.99 x 2.4 mm
Print technology	Dot matrix
Safety	UL, CSA, TÜV
Certification	VCC1, FCC, CE
Country of origin	China
Autocutter durability	1.5 million cuts
Mean time between failures (MTBF)	360000 h
Product color	Black
Maximum roll diameter	83 mm
Supported paper width	80 mm
Printing media thickness	60 - 90 µm
Ethernet LAN	No
Input current	1.8 A
Power supply type	DC
Pallet width	800 mm
Pallet height	1675 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	40 pc(s)
Quantity per pallet (UK)	50 pc(s)
Quantity per pallet layer	8 pc(s)
Quantity per pallet layer (UK)	10 pc(s)
Package depth	382 mm
Package width	285 mm
Package height	305 mm
Package weight	6600 g
Quantity per pack	1 pc(s)
