6 • SET-UP
34 / 144
Art.-Nr.: 80116-271
04.06
Decoupling
C (C =
capacitor)
V 1.5.x Setting on the decoupling capacitor.
MAX:
Decoupling capacitor with maximum capacity.
Available in HF generator modules 30140-804 and 30140-828.
MIN:
Decoupling capacitor with minimized capacity.
Available only in HF generator module 30140-828. At this setting,
neuromuscular stimuli are reduced in the PULSED APC mode.
Next safety
check
V 1.2.x Self-explanatory.
Tes t p r o -
grams
1
V 1.2.x Error list:
Stores all errors detected and signaled by the control panel.
V 1.2.x Event list:
Stores all events (=information and activations) in a looped mem-
ory.
V 1.2.x Version list:
Shows the software versions of all connected components.
From V 1.4.x onward: Option “safe config.” is available.
2
V 1.2.x EEPROM:
Shows memory usage by the application program on EEPROM.
V 1.2.x HF-CPU error list:
Stores all errors detected and signaled by the “CPU + Sensors”;
up to 16 entries.
V 1.2.x No. HF errors:
Records the frequency of errors detected and signaled by the
“CPU + Sensors”.
V 1.2.x APC error list:
Stores all errors detected and signaled by the APC.
V 1.2.x No. APC errors:
Records the frequency of errors detected and signaled by the
APC.
Setting Avaiable from Description
