Command Line Interface
116 1553-CNH 160 0787 Uen PA2 2005-09-23
Figure 41 on page 116)
Netmask 255.255.0.0
Gateway 10.0.100.1
Admin VLAN 247
SNMP Enabled
VLAN Operation Mode Port Based VLAN
VLAN Information VID: 247
All ports must be added as mem-
bers.
Community String Public
Trap managers IP Address 10.0.100.1
EPN124
3
rd
Party Switch
ECN
Port 2
Configure
Static IP Address
10.0.0.2
Port 24
Figure 41 Configure 3
rd
Party Switch
Example
ecn330(config)# ecn unmanaged-switch add port 2 ip
10.0.0.2
11.6.3.7 ip
Configurations related to IP.
