Using a MIB Browser
162 1553-CNH 160 0787 Uen PA2 2005-09-23
In the last example (300012), the IP DSLAM is connected directly to the
ECN on port 3. The line identifier may be written as 300012 or 0300012.
Figure 43 on page 162 illustrates how the Line Identifier is used in the in-
stance. Note that not all OIDs has a PVC as an instance, in which case,
only the Line Identifier is added to the OID.
1.3.6.1.4.1.193.72.300.30.1.3.1.17.300012.2
OID (for Peak Cell rate )
EAN Line
identifier
PVC
Instance
Figure 43 OID to an Embedded Node
In the following examples, the integrated MIB Browser of HP OpenView is
used. It is always a good idea to start by checking the inventory of the EAN.
This is done by querying the empInventoryProductNumber parameter, see
Figure 44 on page 163. Note that the port number in the result is given as
for example 3.0, which is an EDN connected directly to port 3.
This query is performed toward the ECN and therefore no line identifier is
needed.
