ESAB 100i - Page 101

100i / 200i / 300i / 400i
Manual PN: 0560956430 PARTS LISTS 101
100i, 200i, 300i, 400i Torch Leads
Key Description
4 ft
1.2 m
10 ft
3.05 m
15 ft
4.5 m
20 ft
6 m
25 ft
7.6 m
30 ft
9.1 m
35 ft
10.6 m
40 ft
12 m
50 ft
15.2 m
60 ft
18.3 m
75 ft
22.8 m
100 ft
30.5 m
125 ft
38.1 m
150 ft
45.7 m
175 ft
53.3 m
A,B,C,D,E Supply Lead Set (Note 1) 4-3096 4-3097 4-3098 4-3099 4-3100 4-3101 4-3105 4-3102 4-3103 4-3104
A Pilot Return Cable 9-4890 9-4891 9-4790 9-4791 9-9426 9-4792 4-3200 9-4793 9-4794 9-4796
B Negative Cable 9-7356 9-7357 9-7358 9-7359 9-7360 9-7361 4-3201 9-7362 9-7363 9-7364
C Hose, Coolant Supply 9-4805 9-4887 9-4806 9-4807 9-9424 9-4808 4-3202 9-4809 9-4810 9-4812 D Hose, Coolant Return 9-4813 9-4889 9-4814 9-4815 9-9425 9-4816 4-3203 9-4817 9-4818 9-4820
E Control Cable to Arc Starter 9-4941 9-4916 9-4917 9-4918 9-9428 9-4942 4-3205 9-4943 9-4944 9-4922
F Ground Wire, PS to GCM 9-4923 9-4924 9-4925 9-4926 9-4927 9-4928 9-4929 9-4930
F1
Ground Wire, Remote AS to Earth
9-4931 9-4932 9-4933 9-4934 9-4935 9-4936 9-4937 9-4938
G Assembly, Torch Lead 4-5200 4-5201 4-5202 4-5203 4-5204 4-5205 4-5206 4-5207 4-3016
I Plasma Lead 9-3333
J Shield Lead 9-3334
K Control Cable, PS to DMC-3000 9-4907 9-4908 9-4909 9-9332 9-4910 9-4911 9-4912 9-4913 9-4914
O Work Cable 9-7350 9-7351 9-7352 9-7353
P Control Cable, CNC to PS 9-7368 9-7369 9-7370 9-7371 9-7372
H,L,Q,R,S,T, U Auto Gas Lead Set (Note 2) 4-3086 4-3087 4-3088 4-3089 4-3090 4-3091 4-3092 4-3093 4-3094 4-3095
H Plasma Gas Hose 9-7103 9-7104 8-0149 9-7270 9-7271 9-7272 9-7273 9-7274 9-7275 9-7276
L Control Cable Fiber Optic 9-4898 9-4899 9-4900 9-9335 9-4901 9-4902 9-4903 9-4904 9-4905 9-4906
Q Shield Gas Hose 9-7277 9-7278 9-7279 9-7280 9-7281 9-7282 9-7283 9-7284 9-7285 9-7286
R
Pilot Gas/Pre-Flow Hose
9-6956 9-6957 9-6959 9-6961 9-6963 9-6964 9-7080 9-7081 9-4876 9-4877
S Control Cable 9-7093 9-7094 9-7095 9-7096 9-7097 9-7098 9-7099 9-7100 9-7101 9-7102
T Water Shield 9-6985 9-6986 9-6987 9-6988 9-6989 9-6996 9-6991 9-6992 9-6993 9-7073 9-7074 9-7075 9-7076
U Marking Cable 9-4725 9-4726 9-4727 9-4728 9-4729 9-4730 9-4731 9-4732 9-4733 9-4734 9-7077 9-7078 9-7079
V Remote Control Cable 9-9230 9-9231 9-9232 9-9233 9-9234 9-9235 9-9236 9-9237 9-9238 9-9239
W
Communication Control Cable, CNC
9-8674 9-8675 9-8676 9-8677 9-8678 9-8679 9-8680
NOTE 1: Supply lead sets inslude Pilot Return Cable, Negative Cable, Coolant Supply & Return Hoses and Control Cable.
NOTE 2: Auto Gas lead sets include Plasma Gas Hose, Shield Gas Hose,Fiber optic cable, Preow Gas Hose, Water Shield and Control Cables individually, not combined.
